• Total Pixels NTSC: 537 (H) x 505 (V) PAL: 537 (H) x 597 (V)
• Effective Pixels NTSC: 510 (H) x 492 (V) PAL: 500 (H) x 582 (V)
• Resolution With 420 TV Lines
• Sync System Internal
• Scanning System 2:1 Interlace
• S/N Ratio More than 45 dB ( AGC Off )
• Electronic Shutter Auto Electronic Shutter 1/60 (1/50) - 1/100,000 sec.
• Minimum Illumination 0Lux (F2.0) with IR LED On
• Video Output Composite 1.0 Vp-p/75ohms
• Automatic Gain Control On
• Aperture Correction Yes
• Frequency Horizontal NTSC: 15.734 KHz, PAL: 15.625KHz
• Frequency Vertical NTSC: 59.94 Hz, PAL: 50Hz
• IR Operation Range 3.75 ± 3Lux IR On/Off
• LED Angle 4PCS 70° / 2PCS 50° t o t al 6PCS LED
• Lens Mount Type 2.27mm F2.0
• View Angle H: 122° V:91°
• DC Power Source DC 9.6 - 12V
• Power Consumption 3W ( Max IR On )

Audio Functions

• Audio Out 700mV ( 10K OHM )
• Dimensions 88.4 (W) x 66.5 (H) x 51.6 (D) mm
• Operating Temperature -20° C t o 70° C
• Storage Temperature -30°C to 80°C
